| MOQ: | 2 pieces |
| Price: | $801.90 - $3,422.80/pieces |
| Supply Capacity: | 100000 Piece/Pieces per Month |
|
System Composition Parameters
|
|
|
|
Combination method
|
PACK*2-15
|
|
|
Mean Operation Voltage
|
48V-50V
|
|
|
Discharge Cut-off Voltage
|
<=41V
|
|
|
Charging Voltage
|
58.4V
|
|
|
Standard charge
|
Standard
|
|
|
Standard discharge
|
50A*P
|
|
|
Maximum Continuous Charge Current
|
50A*P
|
|
|
Maximum Continuous Discharge Current
|
180A*P
|
|
|
Communication
|
It has CAN and RS485 standard communication interface, it real-time monitoring the capacity of battery bank, the voltage, current,environment temperature, and charging/discharging current,
RS485,CAN,Baud rate:9600Kb/S,CAN COMMON:Master address:CODE 1.slave address:2-15 ,any number |
|
Alarm
|
It has over-temperature, over charge, under-voltage, over-current, short circuit alarm Function.
|
|
Mean Operation Voltage
|
<=40.5V
|
|
Internal Impedance
|
≤100mΩ(Under 20±5℃ Environment Temperature , the Usage Frequency of Fully Charge( 1KHz) , Use AC Internal Impedance test machine to test)
|
|
Max Charging Current
|
100A
|
|
Limited Charging Voltage
|
200A
|
|
Discharge Cut-off voltage
|
41V
|
|
Single module Size/Weight
|
620*442*177mm /90Kg
|
